Common Surface Oxidation and Residue Adhesion Issues in Magnetic Material Sintering Trays: Causes and Optimization Strategies
03 11,2025
Technical knowledge
Surface oxidation and residue adhesion on sintering trays during magnetic material processing significantly impact product yield and performance. This article examines the stability mechanisms of composite alumina-mullite trays under high-temperature reducing atmospheres, detailing root causes such as oxygen diffusion pathways and improper atmosphere control for oxidation, and metal leaching or dust accumulation for residue formation. Practical optimization strategies—including precise kiln atmosphere regulation, tray pretreatment enhancements, and ramp rate matching—are provided to address defects at their source. Real-world case studies illustrate how tray-related failures led to batch rejections, emphasizing the technical value of tray optimization in improving yield consistency and cost efficiency. Engineers can implement these insights directly to enhance sintering outcomes.
Understanding and Solving Surface Oxidation & Adhesion Issues in Magnetic Material Sintering Trays
In high-temperature sintering processes for permanent magnet materials—especially ferrite magnets—tray performance directly impacts yield, consistency, and final product quality. A common but often overlooked issue is surface oxidation and residual contamination on refractory trays, which can lead to scrap rates of up to 12–18% in poorly optimized systems (based on industry data from Chinese ceramic manufacturers in 2023).
“We lost three batches last month due to discoloration and metal residue on the tray surfaces—no one could explain why until we checked the atmosphere control logs.” —— Production Engineer, Jiangsu-based Magnet Manufacturer
Root Causes: Beyond Just "Bad Quality"
Surface oxidation isn’t just cosmetic—it indicates microstructural instability under reducing atmospheres. Common causes include:
- Oxygen diffusion paths: Microcracks or porosity in composite alumina-mullite trays allow oxygen ingress during ramp-up phases.
- Inconsistent atmosphere control: Even a 0.5% deviation in H₂/O₂ ratio can trigger localized oxidation at 1100°C–1250°C.
- Metallic migration: Iron or cobalt from raw powders seep into tray pores and oxidize upon cooling, forming hard-to-remove deposits.
| Issue Type |
Typical Manifestation |
Avg. Impact on Yield |
| Surface Oxidation |
Dark spots, uneven coloration |
~7–10% |
| Metal Contamination |
Black streaks, particle adhesion |
~5–12% |
| Dust Accumulation |
White powder buildup after firing |
~3–6% |
Practical Solutions That Work
Based on real-world trials across 12 production lines, here are actionable steps to reduce defects:
- Pre-treatment optimization: Apply a nano-silica coating before first use to seal pore structure—reduces initial oxidation by ~60%.
- Atmosphere precision: Use online gas analyzers with feedback loops to maintain H₂ concentration within ±0.3% during heating stages.
- Ramp rate adjustment: Slow down from 500°C to 800°C at ≤5°C/min to minimize thermal stress-induced cracking.
These changes have helped clients improve sintering yields from an average of 82% to over 94% within 6 weeks—a return on investment that typically pays off in under 3 months.
